NISSAN Patrol GR I (Y60) 4.2 KAT (165 Hp) Technical сharacteristics
NISSAN Popular Filters
Select the filter you are interested in, if you only want to see the selection for a specific car brand - first go to the brand page and then select the desired filter.
Key Specs |
|
|---|---|
| Fuel system | Petrol |
| Number of cylinders | 4 Cyl. / 4 V per Cyl. |
| Engine volume (Usually, more engine displacement means more power as it can burn more fuel and air) | 4169 cm3 / 4.2 l |
| Power (It is a measure of how much power an engine can produce. Horsepower is the standard unit of measurement of power) | 170 hp 168 bhp |
| Torque | 325 Nm |
| Acceleration from standstill to 100 km/h | 10.6 – 11.7 sec |
| Maximum speed (This is the highest speed the car is capable of travelling) | 165 km/h |
| Combined | 11.6 – 12.7 l/100km |
NISSAN Patrol GR I (Y60) Body, Model and Production details |
|
| Brand | Nissan |
| Model | Patrol |
| Generation | Patrol GR I (Y60) |
| Body (Designations of different versions or iterations of the vehicle model) | Station Wagon | SUV | Pickup |
| Doors | 2 | 3 | 5 |
| Year of putting into production | 1988 |
| Year of stopping production | 1998 |
| Length | 4150 – 4820 mm |
| Width | 1690 – 1800 mm |
| Height | 1790 – 1840 mm |
| Wheelbase | 2380 – 2970 mm |
| Front track | 1410 – 1530 mm |
| Rear track | 1410 – 1535 mm |
| City | 14 – 16 l/100km |
| Highway | 8.5 – 9.6 l/100km |
| Combined | 11.6 – 12.7 l/100km |
| Weight | 2030 – 2190 kg |
NISSAN Patrol GR I (Y60) Engine Technical Data |
|
| Model engine | Piston |
| Position of cylinders | Inline |
| Engine volume | 4169 cm3 / 4.2 l |
| Max power in | 4200 rpm |
| Torque | 325 Nm |
| Turbine | Yes |
| Number of cylinders | 4 Cyl. / 4 V per Cyl. |
| Diameter of cylinders | 96 mm |
| Stroke in the cylinder | 102 mm |
| Compression ratio | 17.9 :1 |
| Number of valves per cylinder | 4 Cyl. / 4 V per Cyl. |
| Fuel type | Petrol |
| Fuel system | Petrol |
| Fuel tank volume | 95 l |
| City | 14 – 16 l/100km |
| Highway | 8.5 – 9.6 l/100km |
| Combined | 11.6 – 12.7 l/100km |
| Power | 165 HPW |
| Torque | 325 Nm |
NISSAN Patrol GR I (Y60) Transmission and gearbox |
|
| Number of gears | Manual 5-speed |
NISSAN Patrol GR I (Y60) Brakes and safety systems |
|
| Wheel drive | 4WD |
| Front brakes | Disc Brakes Brakes |
| Rear brakes | Drum Brakes |
NISSAN Patrol GR I (Y60) Suspension |
|
| Spring, Front | Coil |
| - Suspension, Front | |
| Independent | Multi-link |
| Spring, Rear | Coil |
| - Suspension, Rear | |
| Independent | Multi-link |
NISSAN Patrol GR I (Y60) Exterior |
|
Other Equipment |
|
| Sunroof | Optional |
| Antenna | Whip |
| Rear Wiper | Yes |
| Heated Windows | Rear |
| Heat-Insulating Windows | Optional |
| Second Row | Optional |
Lights |
|
| Rear Lights | Halogen |
| Fog Lights | Yes |
| Rims & Tires | |
| Number of Bolts | 6 |
| Bolt Distance | 139.7 |
| Nut/Bolt Dimensions | M12x1.25 |
| Central Bore (CB) | 110 |
| Fastening Type | Lug Nuts |
NISSAN Patrol GR I (Y60) Interior |
|
Instrument Cluster |
|
| Trip Computer | Optional |
| Speedometer | Analogue |
| Tachometer | Analogue |
| Fuel Gauge | Analogue |
Climate Control |
|
| Air Condition | Optional |
| Outside Temperature Indicator | Optional |
Connectivity |
|
| Radio | AM | FM |
Interior Storage |
|
| Glove Compartment | Light | Lockable Manual |
| Cup Holders | Yes |
| Front | Optional |
| Placement | Middle Console |
Lights |
|
| Read Light | Front |
| Front | Laminated |
| Guide Light | Entry Guard | Bottom of the Doors |
Other Equipment |
|
| Make-up Mirror | Driver Side | Passenger Side |
| Make-up Light | Optional |
| Clock | Optional |
| Digital | Optional |
| Power Steering | Hydraulic |
| Adjustments | Mechanical |
| Colour | Black |
Trunk |
|
| Rear Trunk | Yes |
| Hatch Opening Type | Two-parted Doors |
Seats |
|
- Front Seats |
|
-- Adjustments, Driver |
|
| Seat Depth | Manual |
| Seat Height | Optional |
| Backrest Angle | Manual |
| Headrest, Height | Manual |
-- Adjustments, Passenger |
|
| Seat Depth | Manual |
| Seat Height | Optional |
| Backrest Angle | Manual |
| Headrest, Height | Manual |
| Heated Seats | Optional |
- Back Seat |
|
| Collapsible | Manual |
| Split Fold Ratio | 50/50 |
-- Headrests |
|
| Outer Seats | Height Adjustment |
| Number of Seats | 2 |
| Type of Seat | Adult |
NISSAN Patrol GR I (Y60) Car functions |
|
| Cruise Control | Optional |
NISSAN Patrol GR I (Y60) Safety & Security |
|
- Accessories |
|
| Tool Kit and Jack | Yes |
| Warning Triangle | Yes |
| First Aid Kit | Yes |
- Seat Belt |
|
| Three-Point-Belt | Front Seats | Outer Rear Seats |
- Assist Systems |
|
| Electronic Stability Control | Optional |
- Brake Systems |
|
| Anti-lock Braking System (ABS) | Optional |
| Front | Optional |
| Rear | Optional |
- Other Features |
|
| Immobiliser | Optional |
| Central Locking | Yes |
| Other | |
- Identification |
|
-- VIN Location |
|
| Engine Compartment, Bulkhead | Right |
- Car Classification |
|
| American Classification | Full-Size SUV |
| British Classification | Large 4x4 |
| Australian Classification | Upper Large SUV |
| European Segment | J-Segment |
- Spare Parts BETA |
|
-- Bulb Types |
|
| Low Beam | Halogen |
| Main Beam | Halogen |
| Fog Light, Rear | BA15s P21W |
| Positioning-/Parking Lights, Front | W2.1×9.5d W5W |
| Rear/Brake Light | BAY15d P21/5W |
| Reversing Light | BA15s P21W |
| Turn Indicators, Front | BA15s P21W |
| Turn Indicators, Side | W2.1×9.5d W5W |
| Turn Indicators, Rear | BA15s P21W |
